PRECAUTIONS
1. WARNING – RISK OF EXPLOSIVE GASES

a.
Working in the vicinity of a lead-acid battery can be dangerous. Batteries generate explosive gases during
normal battery operation.

b.
For this reason, it is of the utmost importance that prior to each use of your super capacitor jump starter,
you read and follow the instructions provided exactly.

c.
The appliance is not intended for use by young children or infirm persons without supervision. Young children should be supervised to ensure that they
do not play with the appliance.

2.
Read the manufacturer’s manual for the vehicle being started, the manufacturer may have specific
cautions and instructions regarding emergency starting procedures.
3.
Apply the handbrake and select neutral or “park” before attempting to jump start.
4.
Ensure that the ignition switch and all ancillary electrical equipment is switched off.
5.
To reduce risk of a battery explosion, follow these instructions and those marked on the battery.
6.
NEVER smoke or allow an open spark or flame in the vicinity of the battery or engine.
7.
Do not expose the super capacitor jump starter to moisture, heat, rain or snow.
8.
Do not leave in direct sunlight.
9.
Use of an attachment not recommended or sold by the manufacturer may result in a risk of fire, electric shock,
or injury to persons.
10.
Do not use the super capacitor jump starter unless the battery voltage matches the output voltage rating.
11.
Do not operate the super capacitor jump starter in a closed-in area or restrict ventilation in any way.
12.
Do not operate the super capacitor jump starter with damaged cord. If the cord is damaged, the appliance
should be scrapped.
13.
Do not operate the super capacitor jump starter if it has received a sharp blow, been dropped, or otherwise
damaged in any way. Take it to a qualified repair station or local dealer.
14.
Do not disassemble the super capacitor jump starter. Take it to a qualified repair station or local dealer when
service or repair is required. Incorrect reassembly may result in a risk of electric shock or fire.
15.
Referenced jump start testing after full charged. for engine capacity 1.6L-3.0L Max start 13 times. 3.5L- 5.0L
Max start 5 times.
16.
When not in use, switch off and store in cool and dry place out of the reach of children.

Important Notice: DO NOT use other DC output cords than the one supplied or use an extension cords as it could result in damage to the unit which will not be covered by warranty.

Attention :
The appliance have a wrong polarity protection circuitry built in –But as a good practice , never allow the two clamps touch each other .

opearting instruction:

1. The device is designed for car jump start while running out voltage of car battery.

2. OPERATING INFORMATIONS:

a. Cannot start vehicle because of low voltage of car battery, Connects the device to12V car battery by
alligator clamps, red clamp to positive and black clamp to negative,It will transfer all the rest electric
power to the device capacities from car battery and indicates
CHARGING on device screen. By press
START to start vehicle while indicates FULL CHARGE on device within 10 minutes. If not indicates

FULL CHARGE after 10 minutes,means the car battery is running out of voltage. In this case, Please
charge the device via power bank,DC adapter or other car battery, after indicates FULL CHARGE
on

device
screen within 10 minutes. Then press START button to start vehicle.
b. If still can not get it charged for start vehicle from above mentioned operations.
Please use backup ways to recharge the device such as car battery,power bank,laptop etc.

3. CONTROL PANEL INSTRUCTIONS:

1. POWER ON/OFF:
a. Device full Charged, Press START delays 10S (Red button) button to TURN ON and Hold START
delays 10S(Red button) button to TRURN OFF.
b. Device will TURN ON automatically under charging, Unavailable to TURN OFF
c. Device will TURN OFF automatically after 30 minutes without operations and power supply.

2. START VEHICLE:
a. TURN ON device and indicates FULL CHARGE, Connect theClamps correctly with car battery.
b. Press START delays 10S(red button) button, The device will display countdown in 10S. and after 10S,
there will be display “TURN ON NOW ”. The buzzer will also beep to indicate ready to start engine.
During the process of counting down, press the START delays 10S (red button) button again to cancel
the 10S countdown,This humanized design is convenient for one person to operate,there is enough
time to enter the driving position after pressing the button.
c. Press START(green button) to enter the start-up directly. This is convenient for two people to operate at
the same time.
d. The device will display “UNDER VOLTAGE,CHARGE PLEASE” if operating under low battery.

3. LANGUAGE SETTING:
a.Press LANGUAGE BUTTON(yellow button) to enter languange
selecting screen.
b.Select the proper language then press ENTER (blue button) to confirm
and EXIT.

​WARNING:
Modern vehicles contain extensive electrionic systems , it is strongly recomended to check with vehicle manufacturer for any specific instructions regarding the use of jump starter . when charging by external power sourse , don’t charge the appliance with 12V and 5V at the same time , it will damage the appliance and the external power soutces .
